48V300Ah Pouch Cell Lithium RV Battery With High Energy Density and UN38.3 For RV ,Carvan Vehicle

Minimum Order Quantity : 10pcs Price : Negotiation
Packaging Details : PVC case with inner ,carton box outside Delivery Time : 25-30 days
Payment Terms : T/T or L/ C Supply Ability : 50pcs/week
Place of Origin: China Brand Name: SOUNDON
Certification: UN38.3, ROHS,MSDS Model Number: ES-008-48V300AH-01

Detail Information

Voltage,Capacity: 48V300Ah Battery Cell: SEPNi8688190P-15Ah
Configuration: 20P14S Instantaneous Charge Current: 0.3C
Rapid Discharge Current: 0.3C Cycle Life: 2000 Cycles
Battery Size: 800*400*290mm Application: RV ,caravan Vehicle

Product Description

48V300Ah Pouch Cell Lithium RV Battery With High Energy Density and UN38.3 For RV ,Carvan Vehicle






Battery cell  rated voltage 3.65V
Rated Capacity 15Ah
charge cut-off voltage 4.2V
Impedenece <3.5
Battery Pack Configuration 20P14S
Capacity 300Ah
Rated Voltage  50.4V
Working voltage 42-58.8V
charge condition standard  charge current 0.1C
Rapid charge current 0.2C
Instantaneous charge Current 0.3C
Discharge Condition standard discharge current 0.2C
Rapid discharge current 0.3C
Instantaneous discharge Current 0.3C
Impedence <100
Cycle life 2000 times





Soundon New Energy Battery Cell List





Model SEPNi8688190-13.5Ah
(Fast charging/discharging)
SEPNi8688190P-17.5Ah SEPNi11217127P-32Ah SEPNi11100302P-50Ah
Rated Capacity(Ah) 13.5 17.5 32 50
Typical capacity(Ah) 14.2 17.9 32.96 51
Rated Voltage(V) 3.6 3.65 3.65 3.7
Internal Resistance(mΩ) ≤2.5 ≤3.5 ≤2.0 ≤1.5
Thickness MAX(mm) 8.6 8.7 11.5 11.8
Width MAX(mm) 92 92 217 101
High MAX(mm) 195 195 127 303
Power(Wh) 48.6 63.875 116.8 185
Energy Density(Wh/Kg) 178 220 217 252
Energy Density(Wh/L) 315 409 368 512
High Temp performance
(55℃)
≥100% ≥100% ≥100% ≥100%
Low Temp Performance
(-20℃)
≥75% ≥75% ≥75% ≥75%
cycle life  3C/1C >3000 1C/1C>3000 1C/1C>2500




15Ah ARAI  certificate

 48V300Ah Pouch Cell Lithium RV Battery With High Energy Density and UN38.3 For RV ,Carvan Vehicle



Soundon New Energy industry park



48V300Ah Pouch Cell Lithium RV Battery With High Energy Density and UN38.3 For RV ,Carvan Vehicle
