14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck

14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck

    • 14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck
    • 14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck
    • 14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck
  • 14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck

    Product Details:

    Place of Origin: China
    Brand Name: Soundon
    Certification: CE, MSDS, ROSH
    Model Number: SD-EV-388-375

    Payment & Shipping Terms:

    Minimum Order Quantity: 1
    Price: Negotiable
    Packaging Details: wooden package
    Delivery Time: 30 working days after payment
    Supply Ability: 100 units / week
    Contact Now
    Detailed Product Description
    Working Voltage Range: 261V~365.4V Capacity: 375Ah
    Total Power: 14.5kWh Protection Level: IP67
    Battery Material: NCM Prismatic Cells Max Charge Overcurrent: 220A
    Min Discharge Overcurrent: 500A Application: Electric Truck ,electric Pick Up Vehicle,light Truck

    14.5Kwh High Energy Electric Vehicle Batteries For Electric Truck ,Pick Up Truck ,Logistic Vehicle





    Specifications:



    Battery pack capacity :388V375Ah



    Voltage range :324-453V



    Battery system whole energy  145Kwh



    Singal battery cell capacity :15Ah



    Mx charging current :200A



    Max discharge current :650A



    Standard discharging current :200A



    Instant discharging current:500A



    Max continuous  discharging current :375A



    Battery system on Vehicle Waterproof class :IP67



    Cooling system :Air cool



    Electric vehicle battery cell list



    No. Model Voltage (V) Capacity (Ah) Impedance(mΩ) Dimention
    Length (mm) Width (mm) Thickness (mm)
    1 SEPNi8688190P-15Ah 3.65 15 ≤3.5 194±2 91±2 8.3±0.4
    2 SEPNi8688190P-17Ah 3.65 17 ≤3.5 194±2 91±2 8.4±0.4
    3 SEPNi75161227P-30Ah 3.65 30 ≤2.5 226±2 160±2 7.4±0.4
    4 SEPNi8688190P -13.5Ah 3.65 13.5 ≤3.0 194±2 91±2 8.3±0.4
    5 SEPNi11100302P-42Ah 3.65 40 ≤2.5 301±2 99±2 10.9±0.4
    6 SEPNi11164227P-45Ah 3.65 45 ≤2.5 226±2 163±2 10.8±0.4
    7 SEPNi11217127P-32Ah 3.65 32 ≤2.5 125±2 215±2 11.1±0.4
    8 SEPNi54190140P-10Ah 3.65 10 ≤1.5 141±2 191±2 5.2±0.3
    9 SEPFE12212268P-50Ah 3.2 50 ≤0.8 10.9 212 268.5







    Advantages:



     1. with high energy density NCM lithium battery  cell

     2.using international standard VDA module can ensure the battery pack system  safety

     3. battery cell were approved the UN38.3, CE ,MSDS  certification

     4.battery system with IP 67 waterproof class

     5.with intelligent BMS to control the battery pack system

     6. Special design for the electric light truck ,electric pick up vehicle ,electric logistic vehicle







    our company industry park



    14.5Kwh High Energy Electric Vehicle Battery Packs For Pick Up Truck



    Invested by Sound Environment(SZ000826),Sound Global(Stock:HK00967).

    392 Million USD Registered Capital

    2 Million square meters Industry Park area

    50000 Tons NCM & Lifepo4 battery Cathode materials

    9GW Lithium Battery capacity

    Over 500 R&D Team

    A complete lithium industry chain, From lithium battery cathode material, battery cell, BMS, battery pack to battery recycling

    CE, UL, IEC,ARAI UN38.3, MSDS, ROHS

    ISO9000-2015, ISO-14001-2015, ISO/TS16949:2009, OHSA18001
