Place of Origin:
China
Brand Name:
Soundon
Certification:
CE,ROHS,MSDS,CB
Model Number:
SEPNi8688190P-5P1S-3.6V75AH
Specifications:
| battery cell model | SEPNi7688190P-12.5Ah |
|
Bttery type |
NCM material prismatic cells battery |
|
battery Single Capacity |
12.5Ah |
|
battery cell Rated Voltage |
3.6V |
|
Battery cell weight |
270g |
|
battery cell density certificate |
166.7Wh/kg |
|
Impedance |
<2.5mΩ |
|
Working Temperature
|
-20℃~60℃ |
|
Type |
Parameters
|
Remark |
|
Battery model type |
EV--5P1S |  |
|
Configuration |
5P1S
|
|
|
Modules size(H*W*T) |
232.5×97×42 | |
|
Modules Capacity |
62.5Ah | |
|
Modules Voltage |
3.6V | |
|
Modules weight |
1.5kg | |
|
Modules density certificate |
138Wh/kg | |
|
Working Temperature |
-20℃~60℃ |
Battery cells configurate to the battery pack :
| Item | Battery module performance | ||||
| Cell model | SEPNi7688190-12.5Ah(NCM) | SEPFe80125256-20Ah(LiFePO4) | |||
| Capacity of cell battery(Ah) | 12.5 | 20 | |||
| Configuration | 4P1S | 5P1S | 3P1S | 4P1S | 5P1S |
| Dimension mm(H*W*T) | 232.5×97×34 | 232.5×97×42 | 298.5*132.6*28 | 298.5*132.6*36 | 298.5*132.6*44 |
| Rated capacity (Ah) | 50Ah | 62.5Ah | 60Ah | 80Ah | 100Ah |
| Rated voltage (V) | 3.6 | 3.6 | 3.2 | 3.2 | 3.2 |
| Energy density (Wh/Kg) | 137.4 | 138 | 102.7 | 106.7 | 110 |
Electric Vehicles Li polymer battery pack list :
| Module | Voltage | Capacity | Application | Battery cells Type |
| EV-72250 | 72 | 250 | electric car | NCM |
| EV-108200 | 108 | 200 | Electric passenger car | NCM |
| EV-314100 | 313.2V | 100Ah | Electric car | NCM |
| EV-310125 | 309.6V | 125Ah | Electric pure car | NCM |
| EV-38850 | 388.8 | 52 | Electric cleaning vehicle | NCM |
| EV--367200 | 367.2 | 200 | Electric business bus | NCM |
| EV--324100 | 324 | 100 | Electric Logistic Vehicle | NCM |
| EV--108325 | 108 | 325 | Electric transport Vehicle | NCM |
APPLICATION :
Electric vehicle :e-cars, e-buses, e-trucks, fork lifts, e-scooters e- boat, Off-highway Vehicles
.
