Place of Origin:
China
Brand Name:
Soundon
Certification:
CE, MSDS, ROSH
Model Number:
SD-EV-536-160
538V 160Ah electric bus batteries for electric pure vehicles with long cycle time
| Item | Tech Data | Remark | ||
| Rated voltage/Capacity | 538V/160Ah | |||
| Voltage Working Range | 420V---613.2V | |||
| Total power | 86KWh | |||
| Configuration | 8P 168S | |||
| Charge | Max continuous current | ≤160A | ||
| Discharge | Max Instantaneous Current | ≤320A | 30S | |
| Continuous Current | ≤160A | |||
| Working Temp. Range | Discharge: -20℃~45℃ | |||
| Charge: 0℃~45℃ | ||||
| Storage Temperature | -20～25℃ (3-6months, 50%SOC) | |||
| -20～45℃(1-3months, 50%SOC) | ||||
| -20～60℃ (within 1 month, 50%SOC) | ||||
| Relative Humidity | 5%~95% | |||
| Charge retention | ≥95% | 28days, 25℃, SOC50% | ||
| Resistance | ≥20MΩ | |||
| Total weight | ≤1160kg | |||
| Cooling Method | Air cooling | |||
Advantages:
our certification
ISO/TS 16949, ISO 9001, ISO 14000, CB certification, CE certification and other quality test report obtained.
Packaging & Shipping:
The LiFePO4 battery has passed the UN38.3. During the shipment, batteries should be separate to prevent short circuits. The battery should be packed in wooden box under the condition of half capacity 20-50% for shipment.
The violent vibration, impaction or squeezing should be avoided in the transport process; neither is exposed in the sunlight nor rain.
