10ah 3.2v Capacity Rechargeable Li - Polymer Battery For Electric Vehicle

10ah 3.2v Capacity Rechargeable Li - Polymer Battery For Electric Vehicle

10ah 3.2v Capacity Rechargeable Li - Polymer Battery For Electric Vehicle

Product Details:

Place of Origin: China
Brand Name: SOUNDON
Certification: UN38.3, ROHS,msds
Model Number: SEPFe8288190 --3.2V10 Ah

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: PVC case with inner ,carton box outside
Delivery Time: 25-30 days
Payment Terms: T/T or L/ C
Supply Ability: 20000pcs/day
Contact Now
Detailed Product Description
Voltage: 3.2V Discharge Ending Voltage: 2V
Capacity: 10Ah Max Charging Current: 1C
Dimension: Tickness:8.2*Width:8.8*Hight:190(mm) Max Discharging Current: 3C
Charging Ending Voltage: 3.65V Cycle Life: >2000 Times





Great Safety Performance 8288190 3.2V 10AH Rechargable Lithium Ion Battery For Electric Vehicle



specification :



NO . Item Specification
1 Nominal Capacity 10Ah
2 Nominal Voltage 3.2V
3 Discharge cut-off voltage 2.0V
4 Charge Current 0.5C
5 Discharge current 0.5C
6 Max charge current 1C
7 Max discharge current 5C
8 Charge voltage 3.65V
9 Max charge voltage 3.8V
10 Charge time 2.5H (0.5C charging)
11 Operating temperature Charge :0~45℃
Discharge :-20~60℃
12 Storage temperature <1 month: -20~+45℃
≥1 month: -10~+35℃





Description:

  • Output with high efficiency: Standard discharge current is 0.5C, max discharge current is 5C.
  • Good safety performance: no burning, no explosion. Good thermal control.
  • Wide range of working temperature, from -20 to 60℃.
  • Long cycle life, more than 2000 times.
  • Lighter weight and smaller dimension.

Company profile

  • Soundon New Energy is a professional lithium batteries manufacturer with ISO9001 and ISO/TS16949 certification, specializing in LiFePO4 batteries and NCM batteries with CE, CB, RoHS, MSDS certifications etc.





Lithium  NCM battery  and LiFePo4 battery comparison



NCM battery  cell with high energy density  : volume energy density  >320Wh/L ,Weight Energy Density >180Wh/g

can stand the low Temp. at -20 degree

the material cost is acceptable ,wide using market : e car ,digital product



Lifepo4 :with long cycle life >2000times at 80% , steady performance ,safety

             can endure the high temperature at 75 degree
