Place of Origin:
China
Brand Name:
SOUNDON
Certification:
UN38.3 ,CB ROSH
Model Number:
SD-72-100
Specifications:
| Item | ||
| Compound mode | 5 P 24 Series | |
| Rated voltage/Capacity | 72V/100Ah | |
| Voltage Working Range | 60.0～87.6V | |
| Discharge Cut off Voltage | 60V | |
|
Charge Conditions |
Standard charge current | 0.2C |
| Rapid Charge current | 1C | |
| Instantaneous Charge current | 3C | |
|
Discharge conditions |
Standard discharge current | 0.5C |
| Rapid discharge current | 3C | |
| Instantaneous discharge current | 5C | |
| Working Temp. Range | Charge:(0～40)℃ | |
| Discharge: (-20～60)℃ | ||
| Impedance | ≤25mΩ | |
| Cycle life | ≥2000 cycles | |
| Total Weight | ≤100Kg | |
Applications:
Varieties of e-vehicles: electric golf carts, sightseeing cars and hybrid vehicles.
Advantages:
1. Long cycle life
2.With a smart BMS, monitoring the state of batteries, calculating secondary data, reporting that data, ontrolling the environment, authenticating
3.Environmentally-friendly product
4.Good charge and discharge capacity at high/low temperature
5. High safety level: no fire, no explosion, no leakage
6.International advanced automatic production equipment, ensuring the product quality and our supply ability.
Safety performance tests:
1.Constant Humidity & Heat Requirement
2.Vibration
3.Bump
4.Short circuit test
5.Thermal shock (For cell)
6. Heavy shock
