Caravan Motor Mobile Lifepo4 Lithium Battery 12V 8.8Ah With 30C discharge current

Caravan Motor Mobile Lifepo4 Lithium Battery 12V 8.8Ah With 30C discharge current

Caravan Motor Mobile Lifepo4 Lithium Battery 12V 8.8Ah With 30C discharge current

Product Details:

Place of Origin: China
Brand Name: SOUNDON
Certification: UN38.3, ROHS,MSDS,CB
Model Number: SD-ES -12-8.8

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: Negotiation
Packaging Details: carton box outside
Delivery Time: 25-30 days
Payment Terms: T/T or L/ C
Supply Ability: 20000pcs/day
Contact Now
Detailed Product Description
Voltage: 12V Capacity: 8.8Ah
Battery Material: Lifepo4 Battery Cell Charging Current: 80A
Battery Case: ABS Case Weight: 2KG

12V8.8Ah Mobility Power Pack Lifepo4 Lithium Battery With 30C discharge current For Carvant Motor Mover



Battery pack discription :



This Li-Battery development used at Leisure market or Caravan market, to move a caravan without out car connect to the caravan hitch.

Using a so called „Mover“, to run the caravan wheels, driven by Mover to maneuver the caravan. And this Mover needs power supply provided by batterie.



Technical Specifications



capacity ,voltage :12V8Ah

battery material:lifepo4 battery cell

charging current :80A

max output continuous  : 140A

max discharge voltage :14.6V

weight :around 2 KG





Product Advantage :



       Large density capacity, high rate output



       High efficiency output: rated discharge is 2~5C, continuous big current up to 10C, impulse                   discharge(10S) can reach 30C.



       Wide range of temperature application
           When the outside temperature is high at 65℃ which internal temperature as high as 95℃, battery            ensure discharge normally. When temperature is low at -20℃, it can start the motorcycle normally



       Longer cycle life


           Excellent cycle life, the retain capacity is up to 80% after 1500 cycles.



Factors that effect the battery life

  1. Working temperature is too high
  2. Charge the battery in large current frequently
  3. Increase extra electrical load to battery
  4. Engine drive belt slack
  5. Vehicle static leakage current is large
  6. Engine voltage regulator charging voltage is too hight or too low
  7. Vehicle starting too frequently
  8. Long-time aside vehicle without remove the battery negative connection
  9. Battery is not firmly fixed on the vehicle



Soundon lithium battery feature :



1.Unique lithium battery of Lamination Technology with prismatic case



2) .specilist for Electric vehicle and Energy storage battery cells  in Lifepo4 , LI polymer with prismatic case



high energy density Lifepo4 battery and lipolymer battery cells



flexiable dimension and high capacity  lifepo4 battery cells  customize for chose :10Ah ,20Ah ,25Ah ,50Ah ,60Ah

lifepo4 battery energy density : around 140 WH/KG



lifepo4 battery :>3000 times



3.International Product certification : UN38.3,CB ,CE, Rohs ,UL certification



4.Company Quality Approvals : ISO9001,ISO14001,TS16949 quality system standard approved



5.with complicate ERP system to control the cost and quality



Application :



.wireless monitor equipment ,communicatioin equipment

medical equipemnt ,meter and equipment

LED equipment ,traffic light

portable applicance powertool

.toys solar storage

wind energy storage E-scooter.

E-bike medical wheel





Company Introduction :



lithium ion battery cell for Electric vehicle and Energy storage manufactory



what do your company supply



1.Soundon New Energy With a registered capital of $155 million and an investment of $128 million, mainly for battery cathode materials, high capacity lithium ion batteries and electric vehicles.


2. The capacity of lithium battery can reach 2,160 MWH million Ah, high quality lithium battery cathode material (Li-NiCoMn, Li-Mn) up to 30,000 tons.



what certification do your had



 3.company Quality Certification : Soundon possess a full-scale produce qualification, it passed ISO9000-2008 , ISO 140001-2004,ISO /TS 16949 certification.



4. Product certification : Got CE,CB ,UL ,UN38.3,and ROHS International Industry Certification
