Place of Origin:
China
Brand Name:
SOUNDON
Certification:
CE,CB,UL UN38.3
Model Number:
SEPFe8012525P/20Ah-5P1S(3.2V100AH)
100Ah Lithium Ion Car Battery with longer cycle life
Battery cells discription :
|
Monomer battery
|
1 | Rated Voltage | 3.2V | |
| 2 | Capacity | Rated Capacity:20Ah |
Standard Discharge Current: 0.5C Discharge Cut off Voltage: 2.30V |
|
| Min Capacity:20Ah | ||||
| 3 | Impedance | ≤5 mΩ |
battery pack specification :
|
battery pack |
1 | Compound mode | 5P1S series | ||
| 2 | Capacity | Rated Capacity:100Ah |
Standard Discharge Current: 0.33C Discharge Cut off Voltage:2.30V |
||
| Min Capacity:100Ah | |||||
| 3 | Rated Voltage | Average Voltage | |||
| 4 | Working voltage | 2.5～3.65V DC | |||
| 5 | Charge conditions | Standard charge current:0.5C | |||
| Rapid Charge current:1C | |||||
| 6 | Discharge conditions | Standard discharge current:0.5C | |||
| Rapid discharge current:1C | |||||
| Instantaneous discharge current:3C | |||||
| 7 | Impedance | ≤0.6mΩ | |||
| 8 | Working Temperature | Charge | (0～40)℃ | 60±25% humidity | |
Battery pack characteristic:
1. Using standard modules, with more flexible series-parallel connection, meeting the demands of different clients
2. Strict consistency selection of battery modules and cells, assuring the stability of whole system
3. IP67; air impermeability test passed.
4. Particular material and structure optimization, increasing energy density
Applications:
1. Large-scale electric vehicles: electric bus, electric car, E-Tour Car
2. Light electric car: e-bike, e-scooter,e-motorcycle, electric golf cart, e-wheelchair
3. E-tool: electric drill, electric saw, lawn mower and so on
4. Remote control cars, boat, aircraft, toys
5. Solar and wind power generation energy storage devices, Telecom base Station
6. Small medical equipment and portable equipment
